VED E exclusive
THREE PHASE WATER HEATERS
- Variable rate up to 16 l/min (Exclusive)
- Motor valve for variability of volume flow(exclusive)
- Plain text display with energy monitoring function (exclusive / plus)
- Casing made from UV-resistant ABS
- Display can be changed to the top of the appliance
- Max. outlet temperature 55 ºC
The electronic output and water quantity control Temptronic controls the warm water outlet temperature which can be set between 20 and 55 ºC - always right to the degree. In case of pressure and inlet temperature variations, the set temperature is kept constant even if hot water is tapped simultaneously for example at the shower, the bath tub or the kitchen sink - thus the system rules out undesired alternating shower temperature.
Wireless radio operation
ElectronicVED exclusive is the first hot water heater which offers with a bidirectional remote control. A maximum of 4 water-proof remote controls can communicate with the electronicVED exclusive. Thus, the VED E exclusive enables the user to set the temperature right to be desired degree from each and any room Of the house or even directly out of the bath tub without requiring additional wiring. New feature: the appliance display as well offers a bidirectional connection to the appliance electronics. Thus, the uninterrupted and consistent bidirectional communication between the appliance electronics and the remote control will be possible.
Comforts and quality tailored to the user demands
Comforts and quality means more than only reliable hot water temperatures. The VED E exclusiv is certified with the quality label of the Association for gerontological technology granted to especially userfriendly products. It is an innovative solution for a growing market. Thanks to its easy-to-read display, the intuitive operation, its absolute functional safety and its easy-care surface, the VED E exclusive meets the most exacting demands
Features | Exclusive | Plus | standard | pro | pure |
---|---|---|---|---|---|
Temperature Adjustment | Digital | Rotary knob (-) (+) with display) | Rotary knob | for expert only (internal) | |
tapping detection | flow rate sensor | ||||
water flow limiting | motor valve | water flow limiter 6-9 l | water flow limiter 8-10 l optional for INT 12 l/ min | ||
remote control | 1 x per appliance, up to 4 option | No | |||
capable for solar | yes (except for 27kW appliance) considere an anti-scalding protection | New! Yes ( except for 27 kW appliances) consider an anti-scalding protection. | |||
Max. Inlet temperature | 60˚C / 25˚C *for 27kW appliances | 60˚C / 25˚C *for 27kW appliances |
electronicVED exclusiv | unit | VED E 18/8 P | VED E 21/8 P | VED E 24/8 P | VED E 27/8 P |
---|---|---|---|---|---|
Nominal output | kW | 18 | 21 | 24 | 27 |
Electrical connection | - | 400V / 50Hz / 3/PE ~ | |||
Nominal current | A | 26 | 31 | 35 | 37.7 |
Max. Flow rate quantity | l/min | 12 | 14 | 16 | 18 |
Max. Permissible inlet temperature | °C | 55 | 25 | ||
Temperature adjustment range | °C | Between 20˚C and 55˚C, three stages, electronically regulated | |||
Dimensions: Height / Width / Depth | mm | 481 / 240 / 100 | |||
Weight | kg | 4,4 | |||
IP Rating | - | IP 25 |
